PP Meltblown Nonwoven Fabric making machine

GPM Machinery has recently developed the M Melt-blown Non-Woven Fabric Production Line. The main usages of melt-blown fabric are medium-efficiency and sub-high-efficiency filtration, including air filtration, sanitary filtration, and dust mask production, etc. Besides, it can also be used in making medical and sanitary products, industrial wiper, warm materials, oil-absorbing materials, battery separators, imitation leather base cloths, etc.

Quantity:



Inquire Add to Basket

Brand:
GPM

Product Description

GPM Machinery has recently developed the M Melt-blown Non-Woven Fabric Production Line. The main usages of melt-blown fabric are medium-efficiency and sub-high-efficiency filtration, including air filtration, sanitary filtration, and dust mask production, etc. Besides, it can also be used in making medical and sanitary products, industrial wiper, warm materials, oil-absorbing materials, battery separators, imitation leather base cloths, etc.
1) Introduction to the characteristics and advantages of the production line:
1. Adopting special hanger type and gas equalizing type spinning die, melt distribution is uniform.
2. The air pressure of the air nozzle is stable, the airflow on both sides is symmetrical, and the airflow in the width direction is uniform.
3. The specially designed hot air heating device has good heating efficiency and excellent heat exchange efficiency, and low energy consumption.
4. The fiber fineness and fabric surface are even. 6. High-voltage electrostatic electret treatment makes the melt-blown fabric have good filtering effect.
2）Technical parameters

1	Weight（g/m2)	20-100
2	Suitable materials	PP（MFI 1500-1800)
3	Line speed（m/min)	10-60
4	Model	GM240	GM600	GM800	GM1200	GM1600
5	Melt-blown fabric size（mm)	175	525	700	1050	1600
6	Output（kg/24h)	150	350	500	900	1400

3）Equipment list

1	Extruder	Suitable for PP material(need melt pump for high output)
2	M type melt-blown die	Special design, suitable for high-pressure gas laying
3	Special high-pressure air supply	High-pressure air compressor or imported roots blower
4	Receiving cooling device	Speed regulating synchronously with the production line, Teflon conveyor
5	Vacuum adsorption device	Improve the melt-blown efficiency and quality
6	Air heating and drying system	Customized air heater and moisture drying device
7	Slitting device	According to the design, 4rolls/6rolls slitting
8	Winder	Passive structure, switchable
9	Electrical cabinet for whole line	SIEMENS PLC control or OMRON digital indicator, ABB inverter
10	High-voltage electrostatic electret device	The core device for melt-blown fabric, improves the filtering rate
